Flexible Heart FR4 Printed Circuit Board Assembly For LED Light

Flexible Heart FR4 Printed Circuit Board Assembly For LED Light
Flexible Heart FR4 Printed Circuit Board Assembly For LED Light Flexible Heart FR4 Printed Circuit Board Assembly For LED Light

Large Image :  Flexible Heart FR4 Printed Circuit Board Assembly For LED Light

Product Details:
Place of Origin: China
Brand Name: JHD PCB
Certification: UL,RoHs,SGS,ISO9001-2008
Model Number: JHD-PF-2350
Payment & Shipping Terms:
Minimum Order Quantity: 1000pcs
Price: US$0.1-US$4.99
Packaging Details: Vacuum in Carton
Delivery Time: 7-10 days
Payment Terms: T/T, Western Union
Supply Ability: 30000 square meters per month
Detailed Product Description
High Light:

single side pcb

,

double sided PCB

Flexible Heart FR4 Printed Circuit Board Assembly For LED Light


FR4 board information
FR4 board main technical features and application: electric insulation performance stability, good flatness, smooth surface, no pits, thickness tolerance than standard, suitable for application in high performance electronic insulation requirements of products, such as FPC reinforcement plate, tin furnace, high temperature resistant plate, carbon diaphragm, precision swimming star wheel, PCB testing, electrical (electrical) equipment insulation plate, insulation plate, transformer insulation parts, electrical insulation, deflection coil terminal board, electronic switch insulation board, etc.

The characteristics of the aluminum plate
1. Using surface mount technology (SMT)
2. In the circuit design of thermal diffusion is extremely effective treatment
3. Lower operating temperature, improve the power density and reliability, prolong the service life of products;
4. Reduce the size of our products, reduce the hardware cost and assembly
5. Instead of brittle ceramic substrates, better mechanical endurance

Technical Specification For PCB

Number of Layer1 layer
Order Quantity1 to 50,000
Board ShapeRetangular,round,slots,cutouts,complex,irregular
Board TypeRigid, Flexible, Rigid-flexible
Board MaterialFR-4 glass epoxy, FR-4 high Tg, Rohs compliant,Aluminum,Rogers,etc.
Board CuttingShear,V-score,Tab-routed
Board Thickness0.2-4.0mm, Flex 0.01-0.25mm
Copper Weight1.0, 1.5, 2.0 oz
Solder MaskDouble-sided green LPI,Also support Red,White,Yellow,Blue,Black
Silk ScreenDouble-sided or single-sided in white,yellow,black,or negative
Silk Screen Min Line Width0.006'' or 0.15mm
Max Board Dimensions20 inch*20inch or 500mm*500mm
Min Trace/Gap0.10mm, or 4mils
Min Drill Hole Diameter0.01'',0.25mm, or 10mils
Surface FinishHASL,Nickle,Immersion Gold,Immersion Tin,Immersion Silver,OSP,etc.
Board Thickness Tolerance±10%
Copper Weight Tolerance± 0.25 oz
Minimal Slot Width0.12'', 3.0mm, or 120mils
V-Score Depth20-25% of board thickness
Design File FormateGerber RS-274,274D,Eagle and AutoCAD's DXF,DWG




We are able to provide you best electronics services:

  • PCB Production Service. (FR-4,HI-TG,Aluminum,FPC,TEFLON,CEM-1 )
  • FPC,PCB Copy Service.
  • PCB Assembly Service. (SMT, BGA, DIP)
  • IC program with HEX file.
  • PCBA Housing assembly serivce.
  • PCBA Final Functional Testing.
  • PCBA Copy Service.
  • Electronic Components Purchasing & BOM List Purchasing Services.
  • PCB SMT Stencil. (Laser cut & Etching)
  • Cable assembly


Technical requirement for pcb assembly:

1) Professional Surface-mounting and Through-hole soldering Technology
2) Various sizes like 1206,0805,0603,0402 components SMT technology
3) ICT(In Circuit Test),FCT(Functional Circuit Test) technology.
4) PCB Assembly With UL,CE,FCC,Rohs Approval
5) Nitrogen gas reflow soldering technology for SMT.
6) High Standard SMT&Solder Assembly Line
7) High density interconnected board placement technology capacity.


Quote requirement for pcb and pcb assembly:

1) Gerber file and Bom list
2) Clear pics of pcba or pcba sample for us
3) Test method for PCBA


Lead Time

Samples: 3-4 days
Mass Production: 7-15 days(depend on the quantity)

Packing and Shipment

Vacuum package in carton

Payment Terms

T/T,Western Union


Applications of Products:

1. Computers and relevant products: Movable power board, U Disk, network interface, panel computer, cameral, wire-less mouse.
2. Home appliance: smart projector/digital cameral, high-frequency board. Recorder and repeater board, auto audio equipment main board and control board.
3. Wire-less communication: mobile board,. GPS/ direction record board, wireless telephone main board, intercom main board.

4. LED Lighting: LED drive power, LED light panel, LED light belt.


Why us?
Quality
Our UL(E465880)/Rohs standards insure quality assemblies from start to finish. Whether it's a simple custom product or a complex turnkey production run, JHD PCB will adhere to the highest quality standards.

Capable
JHD PCB offers the latest in assembly capabilities and qualifications insuring that quality is built into every product we produce.

Experience
When it comes to your build you want a partner you can depend on. Our management team has over 8years of combined industry knowledge. Our engineering team has over 5 years experience.

Protecting your interests
Protecting your Intellectual Property is job one! Our staff of trained professionals are all working under a strict confidentiality contract and treat your important documentation as they would their own.

Flexibility
JHD PCB prides ourselves on our ability to custom tailor programs around our customers' needs. JHD PCB takes time to listen to your unique business needs and then set out to surpass them.


JHD PCB would like to be your reliable partner in near future!
