Induction Electric Smelting Furnace 500kw 2000KG Melting Rate

Induction Electric Smelting Furnace 500kw 2000KG Melting Rate
Induction Electric Smelting Furnace 500kw 2000KG Melting Rate

Large Image :  Induction Electric Smelting Furnace 500kw 2000KG Melting Rate

Product Details:
Place of Origin: Jiangsu, China
Brand Name: XINLIAN
Model Number: GYT2000
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: negotiable
Delivery Time: 25-30 days after advance payment
Payment Terms: L/C, T/T, Western Union
Detailed Product Description
High Light:

electric induction furnaces

,

electric casting furnace



Induction Electric Smelting Furnace 500kw 2000KG Melting Rate





Description:



1. Minimum Capacity (T): 0.3

2. Power Factor: 0.95

3. Power Consumption(kw) : 500

4. Rated Voltage (V): 380

5. Phase Number: 3

6. Frequency of Input Current (HZ): 50

7. Melting Rate ( KG): 2000

8. Power Consumption(kw h/t) : 500

9. Rating Working Temperature (℃): 1200

10. Hook: 3

11. Cooling System: Water Cooling

12. Rated Capacity (KG): 4000







Specifications:



These equipments are suitable for copper and copper alloy melting and casting.



Type

Content(t)

Ele. Capacity(KW)

Voltage(V)

Temperature(° C)

Melting Rate(t/h)

G/T-0.15-45

0.15

45

380

1200

0.15

G/T-0.3-75

0.3

75

380

1200

0.3

G/T-0.5-120

0.5

120

380

1200

0.5

G/T-0.75-185

0.75

185

380

1200

0.75

G/T-1-240

1

240

380

1200

1

G/T-1.5-400

1.5

400

380

1200

1.5

G/T-2-500

2

500

380

1200

2

G/T-3-700

3

700

380

1200

3

G/T-5-1500

5

1500

380

1200

5

Note: For brass, the Ele. Capacity will be 0.85 of the figure; Temperature(° C): 1250





Induction Electric Smelting Furnace 500kw 2000KG Melting Rate 0Induction Electric Smelting Furnace 500kw 2000KG Melting Rate 1Induction Electric Smelting Furnace 500kw 2000KG Melting Rate 2





Product Introduction:



The born and development of Melting Furnace for copper rod casting system that break the traditional copper and copper alloy producing way shorten the copper processing time. The traditional process is divided three steps of melting and casting, heating process and cooling process



Advantages:



i) Stable product quality;

ii) Low energy consumption;

iii) Removable inductor maintain easily;

iv) PLC controlling, and servo motor driven system;
